Dibiflow 300 is the horizontal flow-pack machine with a completely electronic working system. High quality features and manufacturing standards: easy to use, fast product change, high versatility, possibility to store up to 99 different working programs with personalised parameters, operator touch screen panel for the easy use and fast regulation of the different parameters. Wide range of additional accessories available on request.
The machine is equipped with:
A Driving Group with 3 indipendent brushless motors:
- In-feed chain conveyor belt
- film pulling wheels
- Jaws rotation
- gravity sliding unit at the exit
- 3” colour touch screen
- 220V single-phase voltage 50Hz
A Product Feeding Group:
- Motorized feeding unit with pitches chain
- Parts in contact with the product made in stainless steel
- Lateral adjustable guides
- Adjustable film conformer
OPTIONS
- Motorized out feed belt
- “best before date / product code” printer
- Photocell for the film with registered print
- Fixed film conformer
- Zig zag knife (for the easy bag opening)
- Electronic step/pitch regulation of the infeed belt
- Machine in a full stainless steel execution
- Longitudinal cross cutting knurling
SPECIFICATIONS – DIBIFLOW 300
FILM HOLDER GROUP
- Film holder shaft with centering cones
- Axial regulation of the film roll through handle
- Max film roll width of 300 mm
- Output: 80-100 pc/min
FILM-DRIVING WHEELS
- Double couple of longitudinal welding wheels (heat one for the film sealing and cold one for the film driving)
- Static edge folding plate
TRANSVERSAL JAWS GROUP
- Single-transversal cross jaw with welding design parallel to the bag width
- Straight cut
- Jaw width of 170 mm
